Terracotta covers DOWNLOAD 21,6 Mb
Innovation in cotto cladding.
Description of specification items
Curtain wall realized with “piastra 25 mm”
Supply and installation of a “curtain wall” cladding, composed of a mechanical steel fixing system and Sannini Impruneta terracotta elements, acid-washed and treated:
Primary structure constituted of vertical sections in stainless steel AISI 304 placed at 50 cm distances approximately. Sections are bound to the support slabs and fixed to the wall by means of special straps and expansion bolts equipped with adjustable spacers and anchors for the fastening of the cotto elements.
The cladding is realized with cotto element “piastra 25 mm”, manufactured out of a special clay extracted from the Impruneta area. The elements are supplied in sizes of (l x h x t): 500x250x25 mm. They have normal kerfs on their upper and lower edges and an “arrotato” surface texture. Installation with vertical and horizontal joints of about 6mm. The cotto elements are to be installed carefully in order to avoid possible out of square placement, and to provide compensation for any defects in the existing backup wall or reinforced concrete structure, leaving a space of about 8/10 cm between the back face of the cladding elements and the support wall.
Treatment: the external face of the Sannini cotto element requires acid-washing using a decalcifying acid detergent for the removal of possible efflorescences and surface protection through the application of an impregnation on a siloxane micro-emulsion basis.
Color
Natural Brushed
Extruded terracotta with rustic surface, obtained through working the element’s surface with steel brushes prior to firing. The intense colour of this tile is due to the removal of surface salts during the brushing process.
Tobacco Brushed
Extruded terracotta with rustic surface “arrotato” and fullbody tobacco colouration.
The coloration is being obtained by mixing a composition of oxides into the clay, allowing a uniform colour penetration
Champagne Brushed
Extruded terracotta with rustic surface “arrotato” and fullbody champagne colouration.
The coloration is being obtained by mixing a composition of oxides into the clay, allowing a uniform colour penetration and distribution. All physical and mechanical characteristics remain unaltered.
